seca Scale-up Line
Class III medically approved Product Number ONSHMAUTNNEMR-validated handrail scale with ID-Display and height measurement
Dispatched within 1-3 working days
Quick Overview
Description
Technical Data
Accessories
Precision
- Basic
- Advanced
- Premium
Key-Technical Data
Capacity300 kg
Graduation50 g < 150 kg > 100 g
Net weight4.6 sts
29.0 kg
29.0 kg
Product width801 mm
Product height2,387 mm
Product depth650 mm
Scope of Delivery
- ID-Display™
- Power adapter
- Flat scale seca 655
- Handrail seca 455
- Ultrasonic height measurement seca 257
Product Properties
- Display shows user and patient names or IDs for increased patient safety
- Outstanding precision and high-speed measuring thanks to perfected ultrasound technology
- Large platform made of tested seca Bearclaw Glass® for absolute breakage resistance and perfect hygiene
- Illuminated LED footprints in the weighing platform show patients the correct standing position for accurate height measurement
- Voice guidance to support the measurement process
- Safe weighing with a stable handrail
- Optional animal sticker facilitates measuring and weighing of children
- EMR-validated: transmit measured data directly to an electronic medical record system or printer
State-of-the-art height measurement
The seca Scale-up Line is probably the most modern and future-oriented way to determine height and weight. Firstly, because of the contactless, fast and highly precise ultrasound measurement. Secondly, because of the ID-Display that displays the names or IDs of patients and users during data transfer into the digital patient file (EMR). This means that this measuring station from the seca Scale-up Line is the ideal choice for EMR-integrated weighing and measuring.
Precision
- Basic
- Advanced
- Premium
Key-Technical Data
Capacity300 kg
Graduation50 g < 150 kg > 100 g
Net weight4.6 sts
29.0 kg
29.0 kg
Product width801 mm
Product height2,387 mm
Product depth650 mm
Scope of Delivery
- ID-Display™
- Power adapter
- Flat scale seca 655
- Handrail seca 455
- Ultrasonic height measurement seca 257
Technical Data
Capacity300 kg
Unitkg
Graduation50 g < 150 kg > 100 g
Measuring range100 - 220 cm
Measuring range with attached handrail100 - 220 cm
Graduation measuring range1 mm
Power supplyPower adapter
Turn-off time with power supplyNo switch off
InterfacesEthernet
USB for barcode scanner
Wi-Fi
USB for barcode scanner
Wi-Fi
Optionswith handrail and ultrasonic height measurement
Net weight4.6 sts
29.0 kg
29.0 kg
Product width801 mm
Product height2,387 mm
Product depth650 mm
Platform width600 mm
Platform height70 mm
Platform depth467 mm
Functions and Properties
- Display of user and patient name or ID
- Display date of birth patient
- TARE
- Pre-TARE
- HOLD
- Auto-HOLD
- CLEAR
- Auto-CLEAR
- RESET
- Automatic weighing range switch-over
- Adjustable damping
- Auto-BMI
- Auto-BSA (Body surface area)
- Mother+child function
- Standby mode
- SEND/Auto-SEND
- Wi-Fi
- Ethernet
- Confirm button
- Acoustic signals can be activated
- Customizable shortcut buttons
- Backlighting
