seca Scale-up Line

Class III medically approved Product Number ONSHMAUTNN

EMR-validated handrail scale with ID-Display and height measurement

seca Scale-up Line
Dispatched within 1-3 working days
Request Offer
Quick Overview

Precision

  • Basic
  • Advanced
  • Premium

Key-Technical Data

Capacity300 kg
Graduation50 g < 150 kg > 100 g
Net weight4.6 sts
29.0 kg
Product width801 mm
Product height2,387 mm
Product depth650 mm

Scope of Delivery

  • ID-Display
  • Power adapter
  • Flat scale seca 655
  • Handrail seca 455
  • Ultrasonic height measurement seca 257
Description

Product Properties

  • Display shows user and patient names or IDs for increased patient safety
  • Outstanding precision and high-speed measuring thanks to perfected ultrasound technology
  • Large platform made of tested seca Bearclaw Glass® for absolute breakage resistance and perfect hygiene
  • Illuminated LED footprints in the weighing platform show patients the correct standing position for accurate height measurement
  • Voice guidance to support the measurement process
  • Safe weighing with a stable handrail
  • Optional animal sticker facilitates measuring and weighing of children
  • EMR-validated: transmit measured data directly to an electronic medical record system or printer

State-of-the-art height measurement

The seca Scale-up Line is probably the most modern and future-oriented way to determine height and weight. Firstly, because of the contactless, fast and highly precise ultrasound measurement. Secondly, because of the ID-Display that displays the names or IDs of patients and users during data transfer into the digital patient file (EMR). This means that this measuring station from the seca Scale-up Line is the ideal choice for EMR-integrated weighing and measuring.

Precision

  • Basic
  • Advanced
  • Premium

Key-Technical Data

Capacity300 kg
Graduation50 g < 150 kg > 100 g
Net weight4.6 sts
29.0 kg
Product width801 mm
Product height2,387 mm
Product depth650 mm

Scope of Delivery

  • ID-Display
  • Power adapter
  • Flat scale seca 655
  • Handrail seca 455
  • Ultrasonic height measurement seca 257
Technical Data

Technical Data

Capacity300 kg
Graduation50 g < 150 kg > 100 g
Power supplyPower adapter
Net weight4.6 sts
29.0 kg
Optionswith handrail and ultrasonic height measurement
InterfacesEthernet
USB for barcode scanner
Wi-Fi
Product width801 mm
Product height2,387 mm
Product depth650 mm
Platform width600 mm
Platform height70 mm
Platform depth467 mm
Measuring range100 - 220 cm
Measuring range with attached handrail100 - 220 cm
Graduation measuring range1 mm

Functions and Properties

  • Display of user and patient name or ID
  • Display date of birth patient
  • TARE
  • Pre-TARE
  • HOLD
  • Auto-HOLD
  • CLEAR
  • Auto-CLEAR
  • RESET
  • Automatic weighing range switch-over
  • Adjustable damping
  • Auto-BMI
  • Auto-BSA (Body surface area)
  • Mother+child function
  • Standby mode
  • SEND/Auto-SEND
  • Wi-Fi
  • Ethernet
  • Confirm button
  • Acoustic signals can be activated
  • Customizable shortcut buttons
  • Backlighting
